Note: Calculate up to 3 significant figures. Show all steps. Assume Vp VBE 0.7V(except for the part (I)) and p p+1-100. You must show a general expression using component symbols before using numbers. (4) Assume Vcc 10.7V, R2 1k and R3 0.5k. (a) For R1 - 200k, find the Q-point (IEo and VcEO). (15 pts.) (b) Find the range of R1 that will keep the transistor from saturation, i.e., VceVcesat 0V. (10 pts.) аз
