(Answered) : Problem 4 Find Required Minimum Diameter D Shaft Nearest Mm Find Corresponding Angle Twist Q28025122

Problem 4 Find the required minimum diameter d of the shaft to the nearest mm, and find the corresponding angle of twist of gear A relative to gear D. The shaft is made of A992 steel with the allowable shear stress of tallow 70 MPa. When the gear B supplies 20 kW of power, gears A, C and D withdraw 6kW, 4 kW, and 10 kW, respectively. The shaft is rotating at 600 rpm 600 mm 600 mm 600 mmProblem 4 Find the required minimum diameter d of the shaft to the nearest mm, and find the
