Problem 3 Water at 70°F is discharged from a pump at the rate of 100 gallons per minute in the piping system shown below. Elevation Za-400 3 Schedule 40 pipe300 3 Standard Gate Valve FLOW Four 3 Standard 90 Threaded Elbows 100 Elevation Z1-0 70 2% Globe Lift Check Valve with wing-guided disc installed with reducers in 3 pipe Calculate the following: a) The total equivalent length for pipe, valves and fittings. b) The total coefficient of resistance (K) for length of pipe, valve and fittings, Assume the Moodys friction factor in the pipe averages 0.0175. Using the baseline of the pump discharge as zero(0), what is the total static head of the piping c) system?Problem
